WPS 250 Gear Motor 15kW 20Hp
From 34.600.000₫
Product Introduction
WPS 250 Gear Motor 15kW 20Hp features heavy-duty right-angle drive with an upward-facing output shaft. Built with a heavy-duty cast iron housing for excellent heat dissipation, it is specialized for chemical agitators, industrial crushers, and lifting systems.
- Size: 250mm
- Output shaft diameter: 90mm
- Power: 15kW (20HP) – 3-Phase 380V
- Transmission ratio: From 1/10 to 1/60
- Housing material: Ultra-durable cast iron
- Characteristic: Upward-facing output shaft (load shaft)
⚡ Reliability: Thanh Thai Motor thoroughly tests the machine before shipment. We support nationwide shipping via transport companies and offer a 12-month official technical warranty.
Product Description
The WPS 250 Gear Motor 15kW 20Hp is a gear motor combining an electric motor and a gearbox, offering high utility value, an attractive design, and a compact footprint.
Design Overview of WPS 250 Gear Motor 15kW 20Hp
The worm gearbox is constructed of sturdy cast iron, and the exterior of the motor is coated with electrostatic powder paint to protect it from external damaging factors.
It combines a worm gearbox with a 3-phase electric motor.
- WPS 250 Worm Gearbox:
- Worm gear made of wear-resistant bronze alloy, operating smoothly with good meshing, increasing transmission lifespan.
- Worm shaft made of stainless steel with surface hardening heat treatment, transmitting force powerfully and accurately.
Technical Specifications of WPS 250 Gearbox
The technical specifications of the WPS 250 gearbox help users easily select and install it according to the requirements of the drive system.
| Size | 250 |
| Input shaft diameter | 60mm |
| Output shaft diameter | 90mm |
| Dimensions | 705mm*552mm |
Customers can refer to the gear motor video system produced by Thanh Thai Motor to learn in detail about the structure, operating principles, and practical application capabilities of each product line in various industries. In addition, the comprehensive video library regularly updates many useful contents related to maintenance, troubleshooting common issues, and drive system optimization solutions, helping customers operate equipment efficiently and save operational costs.
When purchasing gearmotors at Thanh Thai Motor, you will receive benefits such as: Warranty up to 24 Months All gearmotor products at Thanh Thai Motor come with an official 24-month warranty. We are committed to clear after-sales service, with quick and transparent processing procedures – ensuring customer peace of mind during use. Nationwide Delivery No matter which province or city you are in, Thanh Thai Motor is always ready to support fast delivery, ensuring on-time delivery, careful packaging, and safe transportation. We supply a full range of 220V gearmotors, variable speed motors, etc., for the diverse needs of customers nationwide. Products Meet European Quality Standards with German Technology Our products are manufactured using modern German technology, meeting European standards. Models such as integrated gearmotors, variable speed motors, or 220V gearmotors all ensure stable operation and superior durability. Competitive Pricing, Good Discounts for Dealers and Bulk Purchasers We offer affordable gearmotors, suitable for projects with limited budgets. In addition, Thanh Thai Motor has special policies and offers for dealers and bulk purchasers. Quality Commitment All 220V gearmotors here are wound with pure copper wire. This ensures powerful, smooth operation and energy savings. Full Certification Documents: CO, CQ,... All products such as integrated gearmotors, conveyor motors, or speed reducers come with full Certificates of Origin (CO) and Quality (CQ), meeting stringent technical requirements in industry. Need advice on choosing the right gearmotor for your needs? Contact Thanh Thai Motor immediately using the methods below:Warranty, Shipping, and Commitment Policies at Thanh Thai Motor
Contact Us
Specifications
General
| Product Type | WPS Geared Motor |
| Rated Power | 15kW – 20Hp |
| Power Range | 0.18kW – 15kW |
| Frequency | 50Hz |
| Voltage | 380/660V |
| Material | Cast Iron and Aluminum Housings |
| Place of Manufacture | German Technology, Manufactured and Assembled in China |
| Brand | JUMAR, ADTECH |
| Warranty Period | Up to 24 Months |
Motor Specifications
| Shaft Diameter | 42mm |
| Keyway | 12mm |
| Speed | 1,400 – 1,500 RPM |
Gearbox Specifications
| Input Shaft Diameter | 42mm |
| Output Shaft Diameter | 90mm |
| Gear Ratios | 1:10 – 1:60 |
Frequently Asked Questions (FAQs)
What type of motor or equipment is the WPS 250 Gear Motor 15kW 20Hp composed of?
The WPS 250 Gear Motor 15kW 20Hp is a combination of an electric motor and a WPS gearbox.
How is the WPS 250 Gear Motor 15kW 20Hp installed?
The WPS 250 Gear Motor 15kW 20Hp is installed via pulleys and couplings.
Is door-to-door delivery available for the WPS 250 Gear Motor 15kW 20Hp?
When purchasing from Thanh Thai Motor, door-to-door delivery to the customer's location is provided.
Does Thanh Thai Motor provide a warranty for purchases?
Thanh Thai Motor has a 24-month warranty policy.
Does the WPS 250 Gear Motor 15kW 20Hp come with certificates?
Yes. All products at Thanh Thai Motor come with full certificates, documents, CO, and CQ, meeting customer requirements.
