ZQ 1-Stage Gearboxes are a basic and effective transmission solution, considered the simple yet powerful “heart” of many machinery systems. With a structure consisting of only one pair of meshing gears, ZQ 1-Stage Gearboxes perform the core task of reducing the rotational speed of an electric motor and significantly increasing torque. This type of gearbox is highly favored due to its compact design, ease of maintenance, and reasonable cost, making it a perfect choice for moderate industrial load applications.
Structure of ZQ 1-Stage Gearboxes
The ZQ 1-Stage Gearbox is the most basic and simplest type of gearbox in the ZQ series, likened to a box containing two gears: a small gear and a large gear.
- Housing: Typically made of sturdy cast steel, its function is to protect internal components from dust and impact. The housing also contains lubricating oil.
- Input shaft: This shaft is connected to the electric motor. It carries the small gear (driving gear).
- Output shaft: This shaft is connected to the working equipment. It carries the large gear (driven gear).
- Gears: Consists of a pair of large and small gears meshing with each other. A 1-Stage Gearbox has only this single pair of gears. They are typically helical gears for smooth operation.
- Bearings: Help the shafts rotate smoothly without vibration.
- Lubricating oil: Fills the gearbox, ensuring smooth rotation of the gears, preventing overheating, and reducing wear.
- Oil seal: The oil seal acts as a protective ring around the rotating shaft. It prevents valuable lubricating oil from leaking out of the gearbox and stops dust, water, or other contaminants from the external environment from entering the gearbox.
- Auxiliary drive unit: Includes couplings and pulleys, belts or sprockets, etc. These are connection components that enable the ZQ gearbox to work in conjunction and synchronize with the electric motor and the equipment it needs to drive.
Operating Principle of ZQ 1-Stage Gearboxes
The operating principle of ZQ 1-Stage Gearboxes is very easy to understand, similar to shifting from a small to a large sprocket on a bicycle:
- When the motor rotates rapidly, it causes the input shaft and the small gear mounted on it to rotate.
- The small gear rotates and transmits power to the meshing large gear. Because the large gear is bigger than the small gear, it will rotate slower, thus reducing the speed.
- Although the rotational speed is reduced, in return, the rotational force (torque) transmitted to the output shaft is significantly increased.
- Finally, the output shaft will rotate at a slower but more powerful speed to drive the load, for example, rotating the wheels of an overhead crane.
Operating Principle of ZQ 1-Stage Gearboxes
Classification of ZQ Gearboxes by Size
Currently, Thanh Thai Motor offers sizes from 200mm (small to medium) to 1000mm (very large, ultra-heavy duty), including:
| Gearbox ZQ 200 | Gearbox ZQ 250 |
| Gearbox ZQ 350 | Gearbox ZQ 400 |
| Gearbox ZQ 500 | Gearbox ZQ 650 |
| Gearbox ZQ 750 | Gearbox ZQ 850 |
| Gearbox ZQ 1000 |
Classification of ZQ 1-Stage Gearboxes by Size
Technical Specifications of ZQ 1-Stage Gearboxes
| Gear Ratio | Typically small ratios such as 6.3, 8, 10, 12.5. The motor’s rotational speed is reduced by approximately 6 to 12.5 times. |
| Structure | 1-Stage gear. Only one pair of large and small gears mesh. |
| Gear Type | Helical gears. Diagonally cut gears help the gearbox run smoothly and quietly. |
| Gearbox Size | Based on center distance (Size) from 200mm to 1000mm. The larger the size, the more powerful the gearbox and the better its load capacity. |
| Input Mounting Type | Tapered shaft type. The input shaft is designed to be tapered for easy connection to the motor’s coupling. |
| Output Mounting Type | Type C (standard plain shaft) or gear type. The output shaft can be a plain shaft for direct connection or a gear for chain drive. |
Technical Specifications of ZQ 1-Stage Gearboxes
Advantages of ZQ 1-Stage Gearboxes
The 1-Stage Gearbox is favored for its simplicity and cost-effectiveness:
- Simple, compact structure: Due to having only one pair of gears, the ZQ 1-Stage Gearbox is much more compact than ZQ 2-Stage Gearboxes or ZQ 3-Stage Gearboxes.
- Low cost: The ZQ 1-Stage Gearbox design has fewer components, resulting in a reasonable price and easier repair and maintenance.
- High transmission efficiency: Because there is only one stage of transmission, less energy is lost due to friction, allowing the gearbox to operate efficiently.
- Suitable for moderate speeds: While it doesn’t reduce speed as much as the 3-stage type, it is suitable for applications that don’t require extremely deep speed reduction while still ensuring good pulling force.
Advantages of ZQ 1-Stage Gearboxes
Applications of ZQ 1-Stage Gearboxes
Thanks to its compactness and reasonable cost, the ZQ 1-Stage Gearbox is often used in systems with moderate loads or those that do not require extremely low rotational speeds:
- Lightweight moving mechanisms: Used for trolley (buggy) or horizontal movement of small overhead cranes in workshops.
- Small to medium conveyors: Providing power for conveyors used in food production lines, packaging, or short-length conveyors.
- Simple processing machinery: Installed in light industrial machinery, small crushers, or equipment that requires rotation but not excessively high pulling force.
Applications of ZQ 1-Stage Gearboxes
