2-Stage Cycloidal Gearbox UDL 0.37kW X0

The 2-Stage Cycloidal Gearbox UDL 0.37kW X0 is a gearbox product line designed for smooth operation, high load capacity, and suitability for applications requiring flexible speed changes such as conveyors, mixers, packaging machines, or automation systems, creating a flexible, durable, and highly efficient drive system.

Design of 2-Stage Cycloidal Gearbox UDL 0.37kW X0

The 2-stage gearbox features a sturdy solid cast iron housing, ensuring superior load-bearing capacity and corrosion resistance. Combined with a powder-coated finish, it not only enhances aesthetics but also helps the device adapt to high-temperature working environments. It is compact yet powerful, helping to increase torque and maintain stable output speed control.

This device series is assembled with an electric motor to create a compact and powerful gear motor product.

Detailed Structure of 2-Stage Cycloidal Gearbox UDL 0.37kW X0

The 2-Stage Cycloidal Gearbox UDL 0.37kW X0 is constructed by combining two different gearboxes: a Mechanical Speed Variator (UDL) and a Cycloidal Gearbox, creating a powerful device. Specifically:

• Mechanical Speed Variator 0.37kW 0.5Hp:
  • Disc plates: Consist of 4 disc plates moving in a circular trajectory to generate frictional force for power transmission.
  • Speed regulator: Usually a handwheel or control lever allowing users to manually adjust the speed.
  • Gearbox: Can be combined with other gearboxes to expand the speed range
• Cycloidal Gearbox X0 (depending on the gear ratio, Cycloid X0 has different power ratings such as Cycloid Gearbox 0.75kW 1Hp, Cycloid Gearbox 1.5kW 2Hp):
  • Input shaft: Receives rotational motion from the motor to begin the reduction process.
  • Cycloid gear: Has a special shape, performing rolling and oscillating movements to reduce speed and increase torque.
  • Output shaft: Transmits the reduced motion to actuators or final equipment.
  • Housing: Made of cast iron or steel, serving to protect internal components from the external environment and shape the overall structure.

Technical Specifications of 2-Stage Cycloidal Gearbox UDL 0.37kW X0

Below are the technical specifications of the 2-Stage Cycloidal Gearbox UDL 0.37kW X0. This transmission unit consists of a 0.37kW Mechanical Speed Variator (UDL) and a Cycloidal Gearbox X0, helping to adjust speed flexibly and generate large torque for various industrial machinery.

Technical Specifications of Mechanical Speed Variator 0.37kW 0.5Hp

The 0.37kW 0.5Hp Mechanical Speed Variator (UDL) is responsible for changing the output speed through a stepless mechanism before transmitting power to the Cycloidal Gearbox. The parameters below help users easily select and correctly install it with the motor and application system.

Technical Specifications of Heavy-Duty Cycloidal Gearbox X0

The Heavy-Duty Cycloidal Gearbox X0 is the primary reduction stage of the drive unit, helping to reduce rotational speed and increase output torque. Below are the parameters regarding dimensions, shaft diameters, and gear ratios for convenient selection and equipment assembly.

Common Applications of 2-Stage Cycloidal Gearbox UDL 0.37kW X0

The 2-Stage Cycloidal Gearbox UDL 0.37kW X0 has diverse applications as follows:

• Mixers: Increase torque to mix heavy or viscous materials.
• Packaging machines: Ensure precise and stable operating speeds for packaging lines.
• Lifting systems: Increase lifting force for material handling equipment, such as winches or cranes.

To better understand the 2-Stage Cycloidal Gearbox UDL 0.37kW X0, customers can refer to the gearbox video produced by Thanh Thai Motor. The video provides a practical introduction to the structure of the UDL speed variator and the Cycloidal Gearbox, assembly methods, as well as speed adjustment capabilities in various applications. In addition, the comprehensive video shares inspection and maintenance instructions along with practical usage experience, helping users operate the equipment correctly and achieve long-term efficiency.

Warranty, Shipping, and Commitment Policy at Thanh Thai Motor

When purchasing gearboxes at Thanh Thai Motor, you will receive benefits such as:

Warranty up to 24 months

Gearbox products at Thanh Thai Motor are covered by a genuine warranty for up to 24 months. Customers can be completely confident in using them with a clear, transparent, and prompt after-sales policy.

Nationwide Delivery

We support fast delivery to all provinces and cities nationwide. Wherever you are, products are guaranteed to arrive on time and safely.

Products meeting European quality standards with German technology

Gearboxes at Thanh Thai Motor are manufactured using advanced German technology, meeting European quality standards. Ensuring high durability and stable operation for extended periods.

Competitive prices, good discounts for dealers and bulk customers

Reasonable prices, many attractive offers for wholesale buyers and distribution agents. The more you buy, the higher the discount – optimizing profits for customers.

Full certification documents: CO, CQ,...

Each product comes with full Certificate of Origin (CO) and Certificate of Quality (CQ). This provides assurance for customers when using them in projects or constructions requiring technical documentation.

Contact for Purchase

Do you need advice on choosing the right gearbox for your needs? Contact Thanh Thai Motor immediately using the methods below:

• WhatsApp: +84966596219
• Email: codienthanhthai@gmail.com
