Electromagnetic Brake 0.18kW 0.25Hp

Electromagnetic Brake 0.18kW 0.25Hp is a device used to mount directly onto a 3-phase electric motor 0.18kW 0.25Hp to decisively and safely stop the motor’s rotational speed, widely applied in industrial sectors such as material handling or systems requiring safety during power outages.

Overall design of Electromagnetic Brake 0.18kW 0.25Hp

The electromagnetic brake is compactly designed to suit narrow installation spaces. In addition, it is made of thick cast iron material while ensuring durability, corrosion resistance, heavy load capacity, and high temperature tolerance.

Structure of Electromagnetic Brake 0.18kW 0.25Hp

Electromagnetic Brake 0.18kW 0.25Hp consists of the following parts:

• Electromagnet: Consists of a coil made of high-conductivity copper wire wound around an iron core to generate a strong and stable operating magnetic field.
• Armature: Features a brake disc that contacts the motor rotor. Made of wear-resistant alloy material, it enhances sudden stopping friction and extends the service life of the electromagnetic brake.
• Control unit: Used to monitor the temperature of the electromagnetic brake. It features a control circuit to adjust the current flowing through the coil and regulate braking force according to application requirements.

Technical specifications of Electromagnetic Brake 0.18kW 0.25Hp

The product is designed to fit electric motors with a power of 0.18kW 0.25Hp.

Technical specifications

Which products can Electromagnetic Brake 0.18kW 0.25Hp be installed with?

Electromagnetic Brake 0.18kW 0.25Hp can be coupled with various motor series and drive assemblies having the same power or installation dimensions.

• 3-phase electric motor power 0.18kW 0.25Hp: Installed for foot-mounted (B3), flanged (B5, B14), and foot-flange mounted (B35) types.
• 1-Phase Electric Motor 0.18kW 0.25Hp: Suitable for motors using a 220V power supply with matching installation dimensions.
• Gear Motor: Installed with NMRV 30, NMRV 40 series or corresponding flanged models.
• WPO, WPDO gear motor: Applied to drive systems using 0.18kW motors with the same mounting standards.
• Helical gear motor: Suitable for gearbox, helical or coaxial series using a 0.18kW motor.

Applications of Electromagnetic Brake 0.18kW 0.25Hp

Electromagnetic Brake 0.18kW 0.25Hp is widely used in industrial and construction systems such as:

• Used to control speed and ensure safety for cargo elevators, helping prevent drops caused by the motor.
• Used in lifting crane equipment and winches to transport goods safely and accurately, ensuring stable operation.
• Used in conveyor systems, maintaining working performance in production lines.

To explore more electromagnetic brake lines with various capacities, you can watch the summary video. Additionally, the electromagnetic brake video will help you learn about the structure, operating principles, wiring methods, and guidance on selecting the appropriate electromagnetic brake for each motor type.
